SeaFrogs 60M/195FT Waterproof housing for Sony A6xxx series Salted Line with 6" Dry dome port / GEN 3

  Compatible lenses & ports list

Compatible cameras:

• Sony a6000
• Sony a6100
• Sony a6300
• Sony a6400
• Sony a6500

 Please indicate the model of camera and lens which you will be using in "special instructions" at cart page. We will preinstall parts needed and test the unit functionality before shipping.

GEN 3 - an indication of the third generation of Sea Frogs Salted Line waterproof housing for Sony A6xxx camera series featured with two O-rings on a front and backplate, stainless steel latches with red locking pin, and the metal plate on the bottom for better force distribution. Sea Frogs Salted Line waterproof housing for Sony A6xxx camera series GEN 3 was released for sale in December 2019 and sells as a current model.

Compatible lenses (Standard port 60M/195FT):

• Sony E 10-18mm f4 OSS (Autofocus only, Manual zoom available)
• Sony E 16-50mm f3.5-5.6 PZ OSS (Autofocus only, Manual zoom available)
• Sony E 18-55mm f3.5-5.6 OSS (Autofocus only)
• Sony E 20mm F2.8 (Autofocus only)
• Sony E 30mm f3.5 e-mount Macro (Autofocus only)
• Sony FE 28mm F2 (Autofocus only)
• Sony E 35mm f1.8 OSS (Autofocus only)
• Sony E 50mm f1.8 OSS (Autofocus only)
• Sigma 19mm f2.8 DN Art E mount (Autofocus only)
• Sigma 30mm f1.4 DC DN E mount (Autofocus only)
• Sigma 30mm f2.8 EX DN E mount (Autofocus only)
• Sigma 60mm f2.8 DN Art E mount (Autofocus only)
• Samyang 12mm F2 NCS CS (No manual focus or aperture control)

Compatible lenses (6" dome port 40M/130FT):

• Sony E 10-18mm F4 OSS (Autofocus only, Manual zoom available)
• Sony E 16-50mm F3.5-5.6 PZ OSS (Autofocus only, Manual zoom available)
• Sony E 16-70mm F4 ZA OSS (Autofocus only, Manual zoom gear not included)
• Sony E 20mm F2.8 (Autofocus only)
• Sony FE 28-70mm F3.5-5.6 OSS (Autofocus only, Manual zoom not available)
• Sony FE 24-70mm F4 ZA OSS (Autofocus only, Manual zoom not available)
• Sony FE 16-35mm F4 ZA OSS (Autofocus only, Manual zoom not available)
• Sony E 24mm F1.8 ZA (Autofocus only)
• Sony FE 28mm F2 (Autofocus only)
• Sony E 30mm F3.5 Macro (Autofocus only)
• Sony FE 35mm F1.4 ZA (Autofocus only)
• Sony FE 35mm F2.8 ZA Carl Zeiss Sonnar T* (Autofocus only)
• Sony E 50mm F1.8 OSS (Autofocus only)
• Sony FE 55mm F1.8 ZA Carl Zeiss Sonnar T* (Autofocus only)
• Sigma 16mm F1.4 DC DN Sony E-mount (Autofocus only)
• Sigma 19mm F2.8 DN Art (Autofocus only)
• Sigma 30mm F2.8 DN Art (Autofocus only)
• Sigma 30mm F1.4 DC DN | C for Sony E-mount (Autofocus only)
• Sigma 60mm F2.8 DN Art (Autofocus only)
• Rokinon / Samyang 8mm F3.5 UMC Fish-Eye CS II (Manual focus not available, Set to infinity)
• Samyang 12mm F2 NCS CS (No manual focus or aperture control)

• Inbuilt leak sensor
• Depth rate of 60m/195ft
• Port for Fiber optic cable
• Port for vacuum test system
• Two 1/4" -20 threaded holes
• Interchangeable port system
• High-quality optical viewfinder
• Double-sided metal hinge lock
• Zoom control for 10-18mm lens & 16-50mm lens
• Detachable Pistol grip with 2 stage trigger (Not Included)
• Multi-coated optical glass standard flat port
• Reinforced metallic bottom plate

Please note, that a standard port that comes with this unit doesn't have a 67mm thread, so it is not possible to attach 67mm accessories such as filters or lenses.

Technical Specifications:

• Width: 21cm (8.2")
• Height: 20.5cm (8")
• Length: 21.5cm (8.4")
• Weight: ±1534 GR (3.3 LBS)
• Buoyancy - Highly positive (Recommended to add 1Kg to make it slightly buoyant. Can be done with aluminium tray and accessories)

Materials:

• Optical acrylic
• Polycarbonate
• Multi coated optical glass
• Stainless steel

Accessible Controls:

• Shutter button
• ON/OFF
• Mode selector dial
• Control dial
• Flash button
• MENU button
• AF/MF - AEL
• Enlarge button
• Video record button
• FN button
• Control wheel
• Center button
• C1 button
• C2 button
• C3/delete button
• Playback button
• Zoom control for 10-18mm & 16-50mm lenses

• Underwater housing with standard flat port
• 6" Dry dome port
• Swap kit for Sony A6000 camera

  (The housing from the package comes ready to be used with Sony A6300 or A6500 camera. The swap kit is only to be used if your camera is Sony A6000)

• Zoom gear ring for 16-50mm lens
• Zoom gear ring for 10-18mm lens
• Silicone grease (5ml)

• User manual
